Stochastic Control Theory

Recommended post: 【Control Theory】 Table of Contents for Control Theory


1. Sigma-algebra

2. Terminology of Stochastic Control Theory

3. Laws of Stochastic Control Theory


a. Reinforcement Learning

b. The Power of Belief



1. Sigma-algebra

Probability Space

Sigma-algebra(σ-algebra)



2. Terminology of Stochastic Control Theory

⑴ Variable definitions

state (system state) xt: denotes a specific value or a random variable; same below

observation yt: in the perfect observation case, yt = xt

noise (system noise), disturbance, primitive random variable wt, vt

system state noise wt

observation noise vt

⑥ primitive random seed creating stochastic uncertainty x0

control ut

control strategy / law / policy gt

system state sequence xt+1 := ft(xt, ut, wt)

observation sequence yt := ht(xt, vt)

control input, action ut := gt(y0:t, u0:t-1). Using all past information is called perfect recall.

⑵ Classification by system sequence

DDS (deterministic system): xt+1 := ft(xt, ut, wt) = ft(xt, ut). yt := ht(xt, vt) = ht(xt). Case where at any time t both the state variable xt and the output variable yt are known

SDS (stochastic dynamical model): xt+1 := ft(xt, ut, wt), yt+1 := ht(xt, vt), wt, vt ≢ 0.

⑶ Classification by control input

open loop control: ut := gt(y0:t, u0:t-1) = gt(u0:t-1).

feedback control: cases where past outputs y0:t influence the control action u

centralized stochastic control : (1) stochastic dynamical system + (2) one controller + (3) controller with perfect recall

multi-controller problem: team problem, competitive game, etc.

⑷ Classification by policy

decision process: a general framework that deals with decision-making problems where state, action, and reward follow through a process

Markov process: (regardless of whether it is a decision process) the future depends only on the current state




Markov chain: among Markov processes, refers to those with a finite or countably infinite state space

controlled Markov chain: Markov chain + decision process


스크린샷 2025-10-05 오전 2 11 59


MDP (Markov decision process): among decision processes, cases where the future depends only on the current state

dynamic programming: recurrence relation (break the time dependence). If MDP refers to the system framework, dynamic programming refers to the methodology.

POMDP (partially observed Markov decision process): an MDP system where only partial information rather than full state information can be used

constrained MDP, constrained POMDP also exist

Related algorithms

Gaussian process: the state process {Xt} is such that any finite subset follows a joint Gaussian distribution

Gaussian-Markov process

Condition 1. {Xt} is a Gaussian process

Condition 2. Markov property: P(Xn+1 ∈ A X0, ···, Xn) = P(Xn+1 ∈ A Xn)



3. Laws of Stochastic Control Theory

Lemma 1. In open-loop control, xt is a function of x0, u0:t-1, w0:t-1, and yt is a function of x0, u0:t-1, w0:t-1, vt


스크린샷 2025-10-05 오전 2 13 47


Lemma 2. open-loop system vs. feedback system

① Under DDS, open-loop and feedback systems are equivalent: because uniqueness of ut in DDS naturally holds,


스크린샷 2025-10-05 오전 2 14 14


② Under SDS, open-loop and feedback systems are not equivalent

Counterexample 1.


스크린샷 2025-10-05 오전 2 14 49


Lemma 3. policy independence: If Wt is independent of X0:t-1, U0:t-1, then ℙ(xt+1g ∈ A | x0:t, u0:t) = ℙ(xt+1g ∈ A | xt, ut) = ℙ(ft(xt, ut, wt) ∈ A | xt, ut) (Markov property), so dependence on policy g disappears


스크린샷 2025-10-05 오전 2 16 25


① In DDS, if you know the current state, you can know the next state immediately, but in SDS, past states matter, so conditional probabilities on the history are important.

② That is, when wt is independent, system evolution follows natural laws + pure noise, so the policy is irrelevant; but if wt depends on the policy, the policy changes the noise distribution, so the future state distribution depends on the policy.

③ Sometimes written as Wt ⫫ x0, U0:t-1, W0:t-2 instead of Wt ⫫ x0, U0:t-1, but the former is a stronger claim.

Lemma 4. Gaussian process (GP)

① Definition: the state process {Xt} is such that any finite subset follows a joint Gaussian distribution

4-1. Even if each Xi is Gaussian, it does not imply {Xi}i∈ℕ is a GP.

○ Example: X2 = X1 I{|X1| ≤ k} + (-X1) I{|X1| > k}, Y = (X1 + X2) / 2 is not a GP

4-2. For Xt+1 = AXt + BUt + GWt, X0 ~ 𝒩(0, ∑0), Wt ~ 𝒩(0, Q), {Xt} is a GP

4-3. Under a feedback policy, {Xt} is generally not a GP

○ Example: If Ut := gt(Yt) = gt(Xt) = Xt2, then X1 = AX0 + BX02 + GW0, which is not Gaussian

⑤ (Note) MMSE (minimum mean-square estimator)


스크린샷 2025-10-05 오전 9 49 29


⑥ (Note) orthogonality principle


스크린샷 2025-10-05 오전 9 50 20


⑦ (Note) LMMSE (linear minimum mean-square estimator): If X and Y are jointly Gaussian, then LMMSE = MMSE holds


스크린샷 2025-10-05 오전 9 50 46


Lemma 5. multi-step prediction

① In general, ℙ(xt+2g ∈ A | xt, ut, ut+1) ≠ ℙ(xt+2g ∈ A | x0:t, u0:t+1)


스크린샷 2025-10-05 오전 9 52 01


② Since ut+1 = gt(y0:t+1, u0:t) that is not independent of u0:t-1 implies information about wt via observation, conditioning on ut+1 breaks the past-independence of wt: here “past” means x0:t-1, u0:t-1

Counterexample 1. In open-loop control, ut+1 = gt(u0:t) holds, so it cannot imply information about wt, hence equality holds.

Counterexample 2. When wt is a constant

Counterexample 3. When ut is defined to have the Markov property and memoryless feedback, e.g., ut = μt(xt): the following is the case yt = xt = ut


스크린샷 2025-10-05 오전 9 54 51


③ multi-step prediction with open-loop control


스크린샷 2025-10-05 오전 9 55 21


Chapman-Kolmogorov decomposition


스크린샷 2025-10-05 오전 9 55 47


Lemma 6. linear Gaussian state-space model

① (Note) Gaussian-Markov process

Condition 1. {Xt} is a Gaussian process

Condition 2. Markov property: P(Xn+1 ∈ A X0, ···, Xn) = P(Xn+1 ∈ A Xn)

② System definition


스크린샷 2025-10-05 오전 9 57 08


○ Markov property: applies even with feedback policy


스크린샷 2025-10-05 오전 9 57 35


○ multi-step Markov property


스크린샷 2025-10-05 오전 9 58 08


○ mean propagation


스크린샷 2025-10-05 오전 9 58 34


○ cross-covariance Cov(Xt+m, Xt)


스크린샷 2025-10-05 오전 9 59 18


○ covariance propagation


스크린샷 2025-10-05 오전 9 59 48


DALE (discrete-time algebraic Lyapunov equation)

○ If the absolute values of all eigenvalues (including complex ones) of a square matrix A are less than 1, the matrix is defined as stable: because A = 0

○ If A is stable, then ∑ = limt→∞t = limt→∞ 𝔼[(Xt - 𝔼[Xt])(Xt - 𝔼[Xt])ᵀ] exists uniquely


스크린샷 2025-10-05 오전 10 01 17


○ Proof of uniqueness of ∑


스크린샷 2025-10-05 오전 10 01 48


○ stability of A is a sufficient, but not necessary condition: ∑ may still exist uniquely even if A is not stable

reachability

○ Definition


스크린샷 2025-10-05 오전 10 02 24


Theorem 1. The following are all equivalent: assume w ∈ ℝs


스크린샷 2025-10-05 오전 10 02 54


○ In condition 3, the noise sequence w should be interpreted as the control input applied to the system; due to them, the system can be steered from 0 to a given state x over n time steps.

Theorem 2. Lyapunov stability test


스크린샷 2025-10-05 오전 10 03 34


○ Note that in condition 2 it is PD (positive definite), not PSD (positive semidefinite)

Lemma 7. Graph Theory

① strongly connected (= irreducible, communicable): a condition where from any node i in the graph one can reach any other node j


스크린샷 2025-10-05 오전 10 04 05

Figure 1. Example of irreducible


스크린샷 2025-10-05 오전 10 04 55

Figure 2. Example of reducible (state 3 is a sink)


② period: the period of a specific node i is the greatest common divisor of the lengths of all paths from i back to i

○ Example: with two nodes A, B connected by two edges A=B, the period of each node is 2


스크린샷 2025-10-05 오전 10 05 44

Figure 3. Example of a matrix with period m

S1 → S2 → ··· → Sm → S1 → ··· has such a cycle


③ aperiodic: all nodes have period 1

○ aperiodic ⊂ irreduicible

○ Example: if each node has a walk to itself, it is aperiodic

④ stationary state: If Pr(xn | xn-1) is independent of n, the Markov process is stationary (time-invariant)

⑤ regular

○ regular ⊂ irreduicible

○ For some natural number k, every entry of the power Mk of the transition matrix M is positive (i.e., nonzero)

⑥ transition matrix


스크린샷 2025-10-05 오전 10 06 49


⑦ Markov policy: ut = gt(xt)

⑧ One can prove the second law of thermodynamics (law of increasing entropy) using a Markov process

○ Because one can simulate the law of diffusion: provided a uniform stationary distribution is assumed

○ Related concept: random walk

Perron-Frobenius theorem

Theorem 1. If a Markov chain with transition matrix P is strongly connected, there exists exactly one stationary distribution q

○ The stationary distribution satisfies Pq = q

Theorem 2. If a Markov chain with transition matrix P is strongly connected and aperiodic, it is called an Ergodic Markov chain and satisfies:

○ Pij: probability of transition from node j to node i. ∑i Pij = 1

2-1. The (i, j) entry Pij(k) of Pk converges to qi as k → ∞: note it converges to the same value for fixed i regardless of j

2-2. Regardless of the initial state x0, the k-th state xk converges to q as k → ∞

Lemma 8. value function

recursive and backward iteration: for example, with present value (discounting future value to present),


스크린샷 2025-10-05 오전 11 12 32


○ JTg ∈ ℝ1×1

○ π0 ∈ ℝ1×n: initial distribution of the Markov chain

○ V0g ∈ ℝn×1: vector of state-wise value functions collecting expected cumulative cost at each state under policy g

Bellman equation: related to the discounted cost problem

○ (Note) time-homogeneous: {xtg}t≥0 and {xtg}t≥τ,∀τ∈ℤ+ follow the same distribution

Condition 1. time-homogeneous transition: Pt(j | i, u) = P(j | i, u) ∀t

Condition 2. time-homogeneous cost: Ct(x, y) = C(x, y) ∀t

Condition 3. stationary policy: gt = g ∀t

○ If all the above hold, one can obtain the following fixed-point equation


스크린샷 2025-10-05 오전 10 10 36


○ Since Pg is stable, all eigenvalues have absolute value less than 1, so det(I - βPg) = β det( (1/β)I - Pg ) ≠ 0


스크린샷 2025-10-05 오전 10 12 01


○ Vg ∈ ℝn×1: vector of state-wise value functions collecting expected discounted cumulative cost at each state under policy g


스크린샷 2025-10-05 오전 10 12 57


○ Pg ∈ ℝn×n: transition matrix; the (i, j) entry is the probability of transition from i to j

Cesàro limit: related to the long-term average cost problem


스크린샷 2025-10-05 오전 10 13 39


Poisson equation: related to average cost


스크린샷 2025-10-05 오전 10 14 13


○ Jg is unique


스크린샷 2025-10-05 오전 10 14 45


○ Lg: relative value function. Lg is not unique ( Lg + α1 ∀α ∈ ℝ is also a solution to the Poisson equation)

○ Existence of solutions


스크린샷 2025-10-05 오전 10 15 31


Lemma 9. When not irreducible

① If Pg is not irreducible, the state space S splits into the transient states T and one or more recurrent communicating classes C1, ···

② transient state: visited only finitely many times. Eventually the process leaves the transient states and enters a recurrent state.

○ The stationary distribution πg assigns probability 0 to all transient states.

③ recurrent state: since a recurrent communicating class is a closed set, no communication occurs with outside nodes

○ i → j: means there exists a path with positive probability from i to j

○ i ↔︎ j: means i → j and j → i; i and j communicate

○ positive recurrent: the mean return time to that state is finite. A chain starting in a positive recurrent state has a unique stationary distribution.

○ null recurrent: the mean return time to that state is infinite. No stationary distribution exists.

○ absorbing state: a state that, once entered, you remain in forever

Example 1. Finite state space

Let S = {0, 1, ···, I}. Since Vg(0) = 0 and C(0, g(0)) = 0, we can focus only on Ś = S \ {0} = {1, ···, I}, the non-absorbing states. Let Ṽg be the value vector for states in Ś, and let Rg be the submatrix of Pg for transitions among states inside Ś. Then the system of equations for these states is Ṽg = c̃ + Rgg. To show uniqueness of Ṽg, suppose there are two solutions Ṽ1g, Ṽ2g. Let their difference be Ug = Ṽ1g - Ṽ2g; subtracting the two equations yields Ug = RgUg = ⋯ = (Rg)nUg = ⋯ = 0 (∵ limn→∞ (Rg)n = 0, method of infinite descent) ⇔ Ṽ1g = Ṽ2g. Thus, in a finite state space where state 0 is absorbing and all other states can reach 0, the first-passage-time cost equation has a unique nonnegative solution.

Example 2. Countably infinite state space


스크린샷 2025-10-05 오전 10 40 17


Uniqueness is not trivial. Assuming the solution is bounded often allows one to show uniqueness. Consider the equation for the difference of two solutions Ug = RgUg. Connecting this to the diagram yields Ug(ℓ+1) - Ug(ℓ) = (λ - 1)(Ug(ℓ) - Ug(ℓ-1)). The consecutive differences Δ(ℓ) = Ug(ℓ+1) - Ug(ℓ) form a geometric sequence with ratio (λ - 1). If |λ - 1| < 1, these differences converge to 0, suggesting a bounded solution. If |λ - 1| ≥ 1, the differences may diverge, implying that uniqueness may fail.

Lemma 10. Martingale

Doob’s theorem

○ σ(X1, X2, ···, Xn): the smallest σ-algebra that makes X1, X2, ···, Xn measurable

○ Doob’s theorem: σ(X1, X2, ···, Xn) is equivalent to the collection of all functions of the form g(X1, X2, ···, Xn)

○ The larger the σ-algebra, the more functions are measurable with respect to it; i.e., the more information it contains.

② filtration

○ a collection of σ-algebras ordered increasingly by inclusion

○ Ordered by ⊆; if ℱ1 ⊆ ℱ2, then ℱ2 is afterwards relative to ℱ1

○ For convenience, let time index t = 0, 1, 2, ⋯; then the filtration is {ℱt}t∈ℤ+ and satisfies ℱs ⊆ ℱt for all s ≤ t

○ Intuition: represents situations where information increases as observations accumulate over time

martingale

○ Property of conditional expectation

○ For any random variable Y, 𝔼[Y | X1, ···, Xn] = 𝔼[Y | σ(X1, ···, Xn)] holds

○ Reason: because σ(X1, ···, Xn) is equivalent to the set of all functions generated by X1, ···, Xn

○ Martingale: a stochastic process {Xt}t∈ℤ+ adapted to a filtration {ℱt}t∈ℤ+ that satisfies all of the following

Condition 1. Xt is ℱt-measurable for all t ∈ ℤ+

○ If s ≤ t ≤ s′ and ℱ>s​ ⊆ ℱt ⊆ ℱs′, then Xt ∈ ℱt is not ℱs-measurable (insufficient information) but is ℱs′-measurable.

Condition 2. 𝔼[|Xt|] is finite for all t ∈ ℤ+

Condition 3. 𝔼[Xt |s] = Xs almost surely for all s ≤ t and all t ∈ ℤ+

Interpretation: Given only the information up to time s (ℱs), the optimal prediction of Xt equals Xs (i.e., the prediction is constrained to Xs).

Remark: The martingale property is needed only when predicting the future from the past. In particular, for s > t we have 𝔼[Xt s] = Xt regardless of whether (Xt) is a martingale (assuming integrability).

○ For s < t, 𝔼[Xt​ ㅣ ℱs] = Xt ​ also holds, because Xs ​is ℱs-measurable and ℱs ⊆ ℱt implies Xs is ℱt-measurable.

○ Note: an i.i.d. process is generally not a martingale (except for the constant process)

○ Application: 𝔼[Ug(Xtg) | Xt-1g] = Ug(Xt-1g)
