Chapter 13. Ethers
Recommended Article: 【Organic Chemistry】 Organic Chemistry Table of Contents
1. Nomenclature
2. Reactions
1. Nomenclature
⑴ Official Nomenclature
① Take an alkane with a higher number of carbon atoms as the main chain.
② Name the remaining portion other than the parent main as alkoxy
③ Number the carbon in the main chain connected to the alkoxy group as 1
④ If there are multiple substituents in the main chain, name them in alphabetical order
○ Example: (3S, 4R)-3-butoxy-4-methylhexane
⑤ Examples
○ 2-methoxybutane
○ 1-ethoxy-3-methylpentane
○ 1-butoxy-2,3-dimethylpentane
○ 1,4-diisopropoxybutane
⑵ Common Nomenclature
① Write the names of substituents on both sides of the ether oxygen in alphabetical order and add the term “-ether”.
② Examples
○ ethyl methyl ether
○ diethyl ether (ethyl ether)
○ diphenyl ether
○ tert-butyl isobutyl ether
○ sec-butyl isopropyl ether
○ cyclohexyl isopentyl ether
2. Reactions
⑴ Low Reactivity
① Ethers are often used as solvents due to their limited reactivity
② Examples of solvents used
○ diethyl ether: also known as ether
○ tetrahydrofuran: also known as THF
○ tetrahydropyran: also known as THP
○ 1,4-dioxane
○ 1,2-dimethoxyethane: also known as DME
○ tert -butyl methyl ether: also known as MTBE
⑵ Reaction 1. Decomposition by HX
① HI and HBr readily react, while HCl reacts less readily
② SN2 Reaction: Nucleophiles attack ethers that do not contain tertiary carbons, considering steric hindrance
③ SN1 Reaction: Ethers containing tertiary carbons result in carbocation formation at the tertiary carbon
④ Phenyl Groups Present
○ Phenyl alkyl ethers: Decomposition between oxygen and phenyl does not occur. However, under HBr or BBr3, phenolization can occur
○ Biphenyl ethers: Ether decomposition does not occur
⑶ Reaction 2. Hydrolysis by H2O, H2SO4
① Ether Formation: ROH + R’OH → ROR’
② Under strong acidic conditions, reverse reaction to ROH and R’OH can occur
⑷ Reaction 3. Protection of THP Ether: Ether protection using DHP (dihydropyran)
① Protection Step
② Deprotection Step
⑸ Reaction 4. Claisen Rearrangement Reaction
① Reactants: allyl vinyl ether or allyl phenyl ether
Figure 1. Claisen Rearrangement Reaction using allyl phenyl ether as reactant
⑹ Reaction 5. Crown Ethers
① Also called phase transfer catalysts, ion carriers, quaternary ammonium salts, cryptands
② Named as 3n-crown-n-ether due to the repeating CH2CH2O structure
③ Form complexes with different ions based on their pore sizes: Can transport cations after coordination, in nonpolar solvents
○ Li+: 12-crown-4-ether (n=4)
○ Na+: 15-crown-5-ether (n=5)
○ K+: 18-crown-6-ether (n=6)
○ Example: KF doesn’t dissolve in acetonitrile, but crown ether ionizes K+ and captures F- ions
3. Synthesis Methods
⑴ Synthesis of Symmetrical Ethers
① Summary: Elimination reactions dominate at high temperatures, while addition reactions dominate at low temperatures
② (not desirable) H2SO4, 180°C: R-CH2OH + H2SO4 → R=CH2. Alcohol E1 Elimination Reaction
Figure 2. Failed synthesis of symmetrical ethers
③ (desirable) H2SO4, 140°C: R-CH2OH + H2SO4 → R-CH2-O-CH2-R
Figure 3. Successful synthesis of symmetrical ethers
④ Drawback: Synthesis of symmetrical ethers yields various ethers (ROR, R’OR, R’OR’), making it unsuitable
⑤ Exceptionally, successful synthesis of unsymmetrical ethers is achieved using a tertiary alcohol as one component (∵ SN1 Reaction)
⑵ Williamson Ether Synthesis: Synthesis of Unsymmetrical Ethers
① Mechanism
○ Step 1. ROH + NaH → RO-Na+ + H2
○ Step 2. RO- + R’I → ROR’ + I- (SN2): Stereochemistry of R’ is inverted
Figure 4. Mechanism of Williamson Ether Synthesis
② (Formula) Reaction of alcohol under NaH, R’X conditions can be considered as an SN2 reaction
③ Limitation: If R’X is not a methyl halide or primary halide alkyl, elimination reaction dominates, making it unsuitable
⑶ Alkoxy Mercuration-Demercuration
① Overview
○ Useful when Williamson Ether Synthesis is not applicable
○ Alkoxy mercuration-demercuration is Markovnikov hydration where ROH is the reactant
○ Similar to oxymercuration-demercuration of alkenes
② (Formula) Reaction under 1. Hg(O2CCF3)2, ROH, 2. NaBH4, HO- conditions
③ Mechanism
Figure 5. Mechanism of Alkoxy Mercuration-Demercuration
○ Hg exposes inner electrons to create a cyclic intermediate
○ ROH, being a weak nucleophile, performs an SN1-like reaction, attacking the carbon with multiple substitutions
